Three Phase Voltage Stabilizer
We manufacture and supply three-phase voltage stabilizers. Please feel free to contact us. Click the button for a quick reply.
Key Information
- Capacity：1KVA-3600KVA
- Input Voltage: AC 304-456V or customized；
- Output Voltage: AC 380V or customized；
- Voltage Regulation Accuracy：±3%；
- Full Certifications: CE, 3C, UL, KC, RoHS / REACH, etc；
- OEM & ODM Servic；
- Protection Functions: Over/Under Voltage, Short Circuit；
- Servo voltage stabilizers have fast response speed, good output waveform, and the capability to handle high-power loads; they are suitable for industrial, commercial, medical, and communication environments with severe grid voltage fluctuations and frequent load variations；
- Minimum Order Quantity: 1 Set；
| Item | Specification |
|---|---|
| Input voltage | 304V-456V |
| Output voltage | 380V |
| frequency | 50/60Hz |
| Specification | 10 KVA-3600KVA |
| Dielectric strength | 200V/60S﹤10MA |
| Insulation resistance | >20MΩ |
| effectiveness | 98% |
| Voltage regulation accuracy | ±3% |
| Waveform distortion | <3% |
| Ambient temperature | -5℃~40℃ |
| Contrast humidity | <95% |
| Temperature rise | <55℃ |
| Voice | <65dB |
| Protective function | Over/under voltage, phase sequence, overcurrent, overload |
Intelligent Regulation
Three‑Phase Independent Control: Balances voltage across all phases, even under an unbalanced grid.
Real‑Time Monitoring: 5″ LCD displays input/output per phase, load current, temperature, and fault codes.
Remote Access: RS485/Modbus interface for seamless integration with SCADA or BMS systems.
Safety & Protection: Over/Under‑Voltage Cutoff at ± 10% of rated output (e.g., 342 V/418 V).
Overload & Short‑Circuit Protection: 150% overload for 5 min, 200% for 1 min; built‑in current limiting.
Three‑Phase Imbalance Guard: Automatically corrects phase imbalances to protect motors and transformers.
Thermal Management: Forced-air IP54 fans (water cooling optional) and a 120°C cutoff sensor.
Manual Bypass: Copper busbar ensures uninterrupted power during maintenance.
Quality Control
- Every voltage stabilizer undergoes a 100% routine inspection before shipment:
Visual & mechanical check → Safety tests (insulation, dielectric strength, earth continuity) → Regulation performance test at no-load / half-load / full-load → Protection function verification (OV/UV/overload/short-circuit/over-temperature) → Full-load aging test → Noise & display check → Final inspection, record filing & packaging. - Max voltage regulation accuracy: ±1%, THD ≤3%, full-load efficiency ≥95%.
- Our products meet IEC standards with CE & RoHS certifications.
Packing & Shipment
- Voltage stabilizers are packed in shockproof, moisture-proof, and rust-proof export packaging. Small units use reinforced cartons; large industrial models adopt IPPC heat-treated wooden crates or pallets. Machines include corner buffers, insulated terminals, and desiccants to prevent condensation and corrosion. Outer boxes are marked with Fragile, This Side Up, Keep Dry and clear shipping marks.
- Air Freight: Complies with IATA rules. Terminals are insulated, and loose metal parts are secured.
- Sea Freight: Enhanced protection against salt spray. Solid wood packaging must carry valid IPPC marks to avoid quarantine detention.
